MDW-22KW\37KW Two Stage Permanent Magnetic VSD Screw Air Compressor For Textile Factory

Adopting two-stage independent compression mainframe, equal pressure ratio, low speed design, 20% air volume increase under the same power.

Protection class IP54, insulation class F, SKF heavy-duty bearings, efficiency 3-5% higher than similar products;

Air inlet valve, 0-100% automatic adjustment of air volume, reducing operating costs.

Inquire Now Product Comparison Next Product

PRODUCT PARAMETERS

Power
KW

Power
HP

Pressure
MPa

Air Delivery
m³/min

Exhaust Temperature
℃

Start Mode

Drive Mode

Cooling

Compression Level

Noise
db(A)

Voltage
V/HZ

Weight
KG

Dimensions (L*W*H）
mm

Outlet Diameter
imch/mm

22KW

30HP

0.7

4.2

≤+15℃
≤Ambient temperature +15℃

Inverter Drive

Direct Drive

Air Cooling

Two stage

≤75

380V/50HZ

760

1580*1080*1290

RP1 1/2

0.8

4.1

3.5

1.3

3.2

37KW

50HP

0.7

7.1

≤+15℃
≤Ambient temperature +15℃

Inverter Drive

Direct Drive

Air Cooling

Two stage

≤75

380V/52HZ

1080

1880*1180*1520

RP1 1/2

0.8

7.0

5.8

1.3

5.4

PRODUCT ADVANTAGES

1. Intelligent control panel:

All-round monitoring and protection: the system is equipped with an intelligent control panel, which can monitor the parameters of the air compressor in real time, including temperature, pressure, humidity, etc., to 1ensure that the equipment operates in a safe and stable state.

2. High efficiency 3-5% higher than similar products:

Compared with similar products, the use of SKF heavy-duty bearings makes the overall efficiency of the system increase by 3-5%, which brings higher economic benefits to users.

3. Protection class and insulation class:

Protection class IP54: The system adopts high-performance protection design and the protection class reaches IP54, which can effectively prevent the erosion of dust and moisture on the equipment and ensure the stable operation of the equipment in various environments.
